Fordge Fitting

Home Products
Fordge Fittings
We are a trusted manufacturer and global exporter of forged fittings, which are precision-engineered for high-pressure, high-temperature, and critical applications. Our forged fittings are made from high-quality materials to ensure strength, durability, and resistance to corrosion. We offer a wide variety of fittings designed to meet international standards and cater to a diverse range of industries, including oil & gas, power plants, petrochemicals, and aerospace.

Stainless & Duplex Steel

Category Details
Range 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS
Form Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap
Stainless Steel ASTM / ASME SA 182 F 304, 304L, 304H, 309H, 310H, 316, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H
Duplex Steel ASTM / ASME SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61

Carbon & Alloy Steel

Category Details
Range 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS
Form Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap
Carbon Steel ASTM / ASME A105, ASTM / ASME A350 LF2
Alloy Steel ASTM / ASME A182 GR F5, F9, F11, F12, F22, F91

Nickel & Copper Alloy

Category Details
Range 15 NB up to 100 NB in 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS, 150 LBS, 250 LBS
Form Socket Weld Fittings: Elbow 90 Deg, Cross, Tee, Elbow 45 Deg, Coupling, Half Coupling & End Cap
Nickel Alloy ASTM / ASME SB 564 UNS 2200 (Nickel 200), UNS 4400 (Monel 400), UNS 8825 (Inconel 825), UNS 6600 (Inconel 600), UNS 6601 (Inconel 601), UNS 6625 (Inconel 625), UNS 10276 (Hastelloy C276); ASTM / ASME SB 160 UNS 2201 (Nickel 201); ASTM / ASME SB 472 UNS 8020 (Alloy 20 / 20 CB 3)
Copper Alloy ASTM / ASME SB 61 UNS NO. C92200; ASTM / ASME SB 62 UNS NO. C83600; ASTM / ASME SB 151 UNS NO. 70600, 71500, C70600 (Cu-Ni 90/10), C71500 (Cu-Ni 70/30); ASTM / ASME SB 152 UNS NO. C10100, C10200, C10300, C10800, C12000, C12200

Hastelloy

Category Details
Grades Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000
Types Hastelloy Union, Hastelloy Coupling, Hastelloy Full Coupling, Hastelloy Cross, Hastelloy Forged Elbow, Hastelloy Hex Nipple, Hastelloy Plug, Hastelloy Bushing, Hastelloy Boss, Hastelloy Insert, Hastelloy Adapter, Hastelloy Socket, Hastelloy Forged Tee, Hastelloy Olets, Hastelloy Weldolet, Hastelloy Sockolet, Hastelloy Elbowlet, Hastelloy Thredolet, Hastelloy Nipolet, Hastelloy Latrolet, Hastelloy Sweepolet, Hastelloy Half Coupling

Inconel

Category Details
Grades Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750
Standard ASTM / ASME SB 564
Types Elbow - 90 Deg. & 45 Deg, Tee - Equal & Reducing, Union, Cross, Coupling - Full & Half, Socket Reducing, CAP, Plug - Hex & Square, Nipples (Hex / Reducing), Bushing, Sockolet, Weldolet, Thredolet, Elbolet, Nipolet

Incoloy

Category Details
Grades Incoloy 800, Incoloy 825, Incoloy 925, Incoloy A-286, Incoloy DS
Types Union, Coupling, Full Coupling, Cross, Forged Elbow, Hex Nipple, Plug, Bushing, Boss, Insert, Adapter, Socket, Forged Tee, Olets, Weldolet, Sockolet, Elbowlet, Thredolet, Nipolet, Latrolet, Sweepolet, Half Coupling

Monel

Category Details
Grades Monel 400, Monel K500
Types Elbows, Equal/Unequal Tees, Concentric/Eccentric Reducers, Full/Half Couplings, Reducing Couplings, Caps, Cross, Unions, Hex/Reducing/Flash Bushings, Plugs, Nipples, Swage Nipples, Reducer Inserts, Boss, Laterals, Street Elbows, Outlets/Branch Connections (Weldolets, Thredolets, Sockolets, Flexolets, Latrolets, Elbolets, Sweepolets, Insert Weldolets, Nippolets, Brazolets, Coupolets)

Specification of Stainless Steel Forged Fittings

Category Details
Specification ASTM A182 / ASME SA182
Dimension Standard ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size 1/8" NB to 4" NB
Type Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure Threaded End - 2000 / 3000 / 6000 LBS. Socket-weld End - 3000 / 6000 / 9000 LBS

Specification of Stainless Steel Forged Fittings

Category Details
Specification ASTM A182 / ASME SA182
Dimension Standard ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size 1/8" NB to 4" NB
Type Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure Threaded End - 2000 / 3000 / 6000 LBS. Socket-weld End - 3000 / 6000 / 9000 LBS
